Description

Since 1991 Pico Technology Limited has been manufacturing award-winning PC-based oscilloscopes that are designed to meet both your budget and technical requirements. From low-cost, entry-level oscilloscopes, to high-precision PC scopes, an oscilloscope from Pico Technology offers the functionality of a traditional digital storage oscilloscope, in a portable and easy-to-use package.

Pico Technology also manufactures data acquisition products that can provide a straightforward answer to your data logging needs. The data loggers require no power supply and simply plug into a USB port on your PC, or an Ethernet port on your PC or network. Every logger is supplied with PicoLog data acquisition software so you can measure, record and analyze your data.

Pico Technology is a UK company who has spent over 26 years leading the industry in the design, development and manufacture of high-performance PC Oscilloscopes and Data Loggers. Now it is the market leader in PC Oscilloscopes - the modern alternative to the traditional benchtop oscilloscope. During that time we have built up an impressive portfolio of products including the PicoScope PC Oscilloscope range with bandwidths up to 25 GHz, resolutions up to 16 bits and mixed-signal and flexibleresolution models, 4 true different inputs and 2GS deep memory models; the TC-08 and PT-104 Temperature Data Loggers; and the multi-award-winning Automotive Oscilloscope Kit.

Pico Technology prides itself on offering innovative, high-quality and affordable alternatives to traditional bench-top test and measurement equipment, designed and built under the ISO9001:2008 quality system. We support a network of distributors in over 60 countries worldwide who are helping to build and maintain our enviable reputation in the industry. Get more information about Pico Technology and its products, please visit our website: www.picotech.com, or call us: +86 21 22265152.

Oscilloscope Series	Channels	Outputs	Analog Bandwidth	Maximum Sampling	Resolution (Enhanched)	Memory	Power	Description
PicoScope 2000A Models	2 or 4	FG + AWG 100 kHz / 1 MHz	10 – 25 MHz	100 to 500 MS/s	8 bits (12 bits)	8 kS to 128 kS	USB	Power and performance in your hand.
PicoScope 2000B Models	2 or 4	FG + AWG 1 MHz	50 – 100 MHz	500 MS/s to 1 GS/s	8 bits (12 bits)	32 MS to 128 MS	USB	Benchtop performance in a pocket-sized scope.
PicoScope 2000A & B MSO Models	2 analog + 16 digital	FG + AWG 1 MHz	25 – 100 MHz	500 MS/s to 1 GS/s	8 bits (12 bits)	48 kS to 128 MS	USB	Benchtop performance in a pocket-sized scope.
PicoScope 3000D Series	2 or 4 + EXT	FG + AWG 1 MHz	50 – 200 MHz	1 GS/s	8 bits (12 bits)	64 MS to 512 MS	USB or AC adaptor	Fast sampling with deep memory.
PicoScope 3000D MSO Series	2 or 4 analog + 16 digital	FG + AWG 1 MHz	50 – 200 MHz	1 GS/s	8 bits (12 bits)	64 MS to 512 MS	USB or AC adaptor	Mixed signal oscilloscopes.
PicoScope 4224 and 4424 Series	2 or 4	None	20 MHz	80 MS/s	12 bits (16 bits)	32 MS	USB	High resolution oscilloscopes.
PicoScope 4262 Series	2 + EXT	AWG and low-distortion sine wave generator.	5 MHz	10 MS/s	16 bits (20 bits)	16 MS	USB	Digital oscilloscope for the analog world.
PicoScope 4444 Series	4 true differential	Probe compensation signal	20 MHz	Up to 400 MS/s	Flexible 12- or 14-bit	256 MS	USB	High-resolution differential oscilloscopes.
PicoScope 4824 Series	8	FG + AWG	20 MHz	80 MS/s	12 bits (16 bits)	256 MS	USB	8 channel oscilloscope.
PicoScope 5000 Series	2 or 4 + EXT	FG or FG + AWG	60 MHz to 200 MHz	1 GS/s	8, 12, 14, 15 and 16 bits (up to 20 bits)	128 MS to 512 MS	USB or AC adaptor	Flexible Resolution oscilloscopes.
PicoScope 6000 Series	4 + AUX input	FG or FG + AWG	250 MHz–1 GHz	5 GS/s	8 bits (12 bits)	256 MS to 2 GS	AC adaptor	Highest performance real-time oscilloscopes.
PicoScope 9000 Series	2 electrical (+ 1 optional optical), 4 electrical	PRBS, Clock, diff. TDR/TDT	5 GHz to 25 GHz	500 MS/s	16 bits	4 kS to 32 kS	AC adaptor	Sampling oscilloscopes.
Voltage Data Loggers PicoLog1000 /ADC20/ADC24	8/12/16 Channels	10/12/20/24 Bits ADC	-	-	-	-	-	-
Current Data Loggers PicoLog CM3	3 Channels	24 Bits ADC	-	-	-	-	-	-
Thermocouple temperature data loggers TC-08	8 Channels	20 Bits ADC	-	-	-	-	-	-
PRT temperature data loggers PT-104	4 Channels	24 Bits ADC	-	-	-	-	-	-
Vector Network Analyzer PicoVNA 106	2 Channels	300 KHz-6 GHz freqency range	-	-	-	-	-	-

View Test & Measurement Catalog Pico Technology Simplified Catalog
